Our Facilities
|
| |
|
|
| |
 |
| |
Fiber Laser Welding Machine
|
| Model: |
HGLW/HGLC-1500E, ML-WF-BP-SCB-JW1500, ACL 1500W |
| Laser Power: |
1500 W |
| Voltage: |
AC 220V |
| Frequency: |
50 HZ |
| Quantity: |
6 units |
|
|
|
| |
|
 |
| |
DYNA ROBOTIC / OTC DAIHEN
|
| Model: |
D6-1510N / AX-V4 AP |
| Axis: |
6 |
| Payload: |
6kg / 4kg |
| Repeat ability: |
±0.08mm |
| Weight: |
172kg / 160kg |
| Welding machine: |
Megmeet Heave CM350 / OTC Digital Inverter DM 350 |
| Use environment: |
0-45°C, 20-80% (No Condensation) |
|
|
|
| |
|
 |
| |
CNC Double
Column Vertical
Machining Center
|
| Model: |
"Hartford" PRO - 3210 AG |
Spindle
Speed Range: |
6000rpm |
| Working Range: |
X 3000mm
Y 2000mm
Z 1070mm |
| Table Size: |
|
|
|
|
| |
 |
| |
CNC Vertical
Machining Center
|
| Model |
Hwacheon Vesta
- 1000/10K |
Spindle
Speed Range: |
10,000rpm |
| Working Range: |
X 1000mm
Y 550mm
Z 500mm |
| Table Size: |
502mm x 1100mm |
|
|
|
| |
 |
| |
CNC Lathe
Machine
|
| Model: |
Takisawa NEX - 108 |
| Turning Speed: |
4000rpm |
| Turning Length: |
481mm |
| Working Range: |
X 180mm
Y 530mm |
|
|
|
| |
|
 |
| |
Bending
Machine
|
| Model: |
NCP200-32 |
| Bending Range: |
3200mm |
| Capacity: |
200 tons |
| Type: |
4 axes CNC Hydraulic
2 axes Backgauge system
CyberTouch 12 Controller |
|
|
|
| |
 |
| |
Panel Bender
|
| Model: |
Salvagnini P2 Lean |
| Panel Dimension: |
L280mm x W119mm - Min.
L2180mm x W1524mm - Max.
Height - Max. 165mm |
| Thickness Range: |
Mild steel - Max. 3.2mm
Stainless Steel - Max. 2.5mm
Aluminium - Max. 4mm |
| Capacity: |
80 tons |
|
|
|
| |
 |
| |
Bending
Machine
|
| Model: |
FMB II NT 1025 |
| Bending Range: |
2500mm |
| Capacity: |
980KN |
| Type: |
7 Axes CNC Hydraulic
Slimming Royalty
Machine |
|
|
|
| |
 |
| |
Bending
Machine
|
| Model: |
FMB II - 3613 NT |
| Bending Range: |
1300mm |
| Capacity: |
360KN |
| Type: |
7 Axes Servo Electric CNC
Press Brake Bending |
|
|
|
| |
 |
| |
Bending
Machine
|
| Model: |
HDS 1303 NT |
| Bending Range: |
3100mm |
| Capacity: |
1425KN |
| Type: |
8 Axes CNC Hydraulic
5 Axes Backgauge
AMNC- PC Control |
|
|
|
| |
|
 |
| |
Fiber Laser Cutting Machine
|
| Model: |
Han's Laser G3015HF |
| Laser Source: |
6000W |
| Working Range: |
1524mm x 3048mm (5ft x 10ft) |
| Thickness Range: |
Mild steel - Max. 20mm
Stainless steel - Max. 12mm
Aluminium - Max. 10mm |
|
|
|
| |
 |
| |
Tube Cutting Laser Machine
|
| Model: |
Han's Laser P6018D-IPG Laser Tube Cutter |
Laser
Source: |
2000W |
| Working Range: |
Mild Steel - Max. 8mm
Stainless Steel - Max. 5mm
Aluminium - Max. 5mm |
| Thickness Range: |
6 meter
- Equal Hollow
- Unequal Hollow
- Tube pipe obround
- C-channel
- Angle Bar |
|
|
|
| |
|
 |
| |
Turret Punch Machine
|
| Model: |
TruPunch 1000 |
Maximum
Working Range: |
X: 2500mm, Y:1250mm |
Maximum Punching
Force: |
165KN |
|
|
|
| |
|
